Professional rechargeable battery test machine.
high dynamic response speed,
high stability and accuracy
support multiple channels.
1A-100A
5V-100V
Quantity:
Contact Now
add to cart

Introduction:
  • Professional rechargeable battery test machine.
  • high dynamic response speed,
  • high stability and accuracy
  • support multiple channels.
  • Test the capacity, cycle life by the different method.
  • Multi-channel input and energy recovery function.
  • Modular design, channel quantity can choose from 1 to 12 in one machine
  • DC and AC modules are used in combination, and the DC BUS is independent;
  • The whole machine adopts copper bus technology, making the inside of the chassis cleaner.

Model List:
Model60V50A 100V100A
Voltage0-60V0-100V
Current0-50A accuracy 1mA0-100A accuracy 1mA
Accuracy0.02%/0.05%0.02%/0.05%
response speed≤3ms≤3ms
Data record100Hz100Hz
Channel 1-12 1-12
Applicated
Power
Energy
feedback module
Energy
feedback module

Contact us to get more details and models of machines for reference.

We can design a series of the battery testers on the basic of the application

OurRechargeable Battery Test Machine is a professional-grade solution for comprehensive battery performance evaluation, designed to meet the rigorous demands of battery manufacturers, R&D labs, and quality control facilities. As a multi-channel battery tester, it supports 1–12 independent channels in a single unit, enabling parallel testing of multiple batteries to improve efficiency and throughput.
Equipped with an energy recovery battery tester function, it recycles up to 90% of the energy discharged during testing, reducing power consumption and operational costs. The high-precision battery cycler delivers exceptional accuracy (0.02%/0.05%) and ultra-fast response speed (≤3ms), ensuring reliable measurements of capacity, cycle life, and dynamic performance across different battery chemistries.
Themodular battery testing system design allows flexible configuration of DC and AC modules, with independent DC buses and copper bus technology for a cleaner, more organized chassis. It offers two main models: 60V50A (0–60V, 0–50A) and 100V100A (0–100V, 0–100A), both with 100Hz data recording to capture detailed performance metrics.
Whether you need to test small-scale lithium-ion cells or high-voltage battery packs, our Rechargeable Battery Test Machine delivers the precision, scalability, and energy efficiency required for modern battery development and production.
